products-perkins - Tender เครื่องกำเนิดไฟฟ้า

Gen Set Model	Perkins Type	Standby Rating		Prime Rating
Gen Set Model	Perkins Type	KVA.	KW.	KVA.	KW.
TP10	403D – 11G	10	8	9	7
TP15	403D – 15G	15	12	13	10
TP22	404D - 22G	22	18	20	16
TP33	1103A - 33G	33	26	30	24
TP50	1103A - 33TG1	50	40	45	36
TP66	1103A - 33TG2	66	53	60	48
TP88	1104A - 44TAG1	88	70	80	64
TP110	1104C – 44TAG2	110	88	100	80
TP115	1006TG2A	110	88	100	80
TP150	1006TAG	150	120	135	108
TP155	1106A – 70TAG1	150	120	135	108
TP165	1006TAG2	165	132	150	120
TP170	1106A - 70TAG2	165	132	150	120
TP200	1106A – 70TAG3	200	160	180	144
TP220	1106A – 70TAG4	220	176	200	160
TP250	1306C - E87TAG4	250	200	227	184
TP275	1306C - E87TAG6	275	220	250	200
TP300	1606A – E93TAG4	300	240	275	220
TP330	1606A – E93TAG5	330	264	300	240
TP385	2206A – E13TAG2	385	308	350	280
TP440	2206A – E13TAG3	440	3520	400	320
TP500	2506A – E15TAG1	500	400	454	360
TP550	2506A – E15TAG2	550	440	500	400
TP660	2806A – E18TAG1A	660	528	600	480
TP700	2806A – E18TAG2	700	560	650	520
TP825	4006 – 23TAG2A	825	660	750	600
TP880	4006 – 23TAG3A	880	704	800	640
TP1100	4008TAG2A	1100	880	1000	800
TP1375	4012 – 46TWG2A	1375	1100	1250	1000
TP1650	4012 – 46TAG2A	1656	1325	1505	1204
TP1875	4012 – 46TAG3A	1875	1500	1705	1364
TP2000	4016TAG1A	2028	1622	1844	1476
TP2250	4016TAG2A	2250	1800	2058	1646
TP2500	4016 – 61TRG3	2420	1936	2200	1760

RATING : All rating data based on operation under
ISO 3046 ,BS5514 , DIN6271 , ISO8528

STANDBY POWER : Standby ratings are for the supply of
emergency power at variable load in the event of a main
power network failure up to a maximum of 500 hours per
year , No overload in permitted.

PRIME POWER : Prime ratings are suitable for continuous
electrical power (at variable load in lieu of main power
network). There is no limitation to the annual hours of
operation and all models can supply 10 % overload power
for 1 hour in 12 hours.
